Are you facing frequent sewer blockages, sludge buildup, and high-risk manual cleaning in municipal pipelines?
Traditional sewer cleaning methods are not only inefficient but also dangerous, especially in confined underground environments.
Our sewer cleaning robot is specifically designed for municipal sewer systems, providing a safe, efficient, and fully remote-controlled solution for pipeline cleaning and sludge removal—without requiring workers to enter hazardous spaces.
Sewer Cleaning Robot Technical Specifications
| Parameter | YG500 | YG600 | YG700 | YG800 | YG900 | YG1200 |
| Robot Dimensions (mm) | 1500*500*650 | 1500*600*650 | 1600*700*650 | 1600*850*700 | 1650*960*750 | 1900*1200*750 |
| Dredging Width (mm) | 500 | 600 | 700 | 800 | 900 | Suitable for large culverts |
| Travel Speed (m/s) | 3–15 | 3–15 | 3–15 | 3–15 | 3–15 | 0–17 m/min |
| Pump Diameter (inch) | 3 | 3 | 4 | 4 | 4 | 4or6 |
| Pump Flow (m³/h) | 100 | 100 | 160 | 160 | 200 | 250 |
| Pump Head (m) | 0–30 | 0–30 | 0–25 | 0–25 | 0–25 | 0–30 (Horizontal: 100–150m) |
| Hydraulic Station Dimensions (mm) | 2200*1200*1700 | 2200*1200*1700 | 2200*1200*1700 | 2200*1200*1700 | 2200*1200*1700 | 2120*1240*1200 |
| Main Motor Power (kW) | 18 | 18 | 22 | 22 | 22 | 45KW (50KW) or Diesel 76KW (123KW) |
| Hydraulic System Pressure (Mpa) | 0–16 | 0–16 | 0–16 | 0–16 | 0–16 | Not specified |
| Particle Size (mm) | 15 | 15 | 40 | 40 | 50 | 0–40 (customizable) |
| Winch Speed (r/min) | 0–10 | 0–10 | 0–10 | 0–10 | 0–10 | 0–10 |
| Pipe Length (m) | 30–50 Optional | 30–50 Optional | 30–50 Optional | 30–50 Optional | 30–50 Optional | 30m/pack, 20kg pressure resistant, optional |
| Control System | Wireless Remote | Wireless Remote | Wireless Remote | Wireless Remote | Wireless Remote | Wireless Remote |
| Lighting System | Underwater LED*2 | Underwater LED*2 | Underwater LED*2 | Underwater LED*2 | Underwater LED*2 | Underwater LED*2 |
👉 Custom solutions are available for different municipal project requirements.
Designed for Municipal Sewer Challenges
Urban drainage systems are complex and difficult to maintain. Common problems include:
- Severe sludge accumulation blocking pipelines
- Limited access in narrow underground spaces
- Toxic gases and oxygen-deficient environments
- High labor costs and safety risks
👉 Our sewer cleaning robot for sale directly addresses these challenges with advanced automation and intelligent control.
Key Features of Sewer Cleaning Robot
✔ Remote Control & Real-Time Monitoring
Operate the robot from the surface with full visibility, ensuring zero-risk operation in confined spaces.
✔ Compact Structure for 600mm Pipelines
Specially designed to enter narrow sewer pipelines (≥600mm diameter), making it ideal for municipal drainage systems.
✔ High-Efficiency Sludge Removal
Equipped with powerful cleaning mechanisms to remove mud, sand, debris, and sediment, restoring pipeline flow quickly.
✔ Explosion-Proof & Waterproof Design
Safe for use in toxic, flammable, and high-humidity environments, ensuring long-term durability.
✔ Strong Mobility with Crawler System
Stable operation on wet, slippery, and uneven surfaces inside pipelines.
Typical Applications in Municipal Projects
Our municipal sewer cleaning robot is widely used in:
1. Underground Sewer Pipelines
Efficiently remove sludge and blockages in city sewer networks.
2. Urban Drainage Systems
Maintain smooth water flow in stormwater and wastewater systems.
3. Culverts and Underground Channels
Clean narrow, enclosed channels that are difficult for manual access.
4. Flood Prevention Systems
Ensure drainage systems remain unblocked during heavy rainfall.
Why Municipal Contractors Choose Our Sewer Cleaning Robot?
✔ Improve Worker Safety
No need for manual entry into confined and hazardous sewer environments.
✔ Increase Cleaning Efficiency
Continuous operation reduces downtime and speeds up maintenance cycles.
✔ Reduce Operational Costs
Lower labor costs and minimize the need for manual intervention.
✔ Reliable for Long-Term Use
Durable design ensures stable performance in demanding municipal conditions.
Real Municipal Project Cases
Our sewer cleaning robots have been successfully used in multiple city projects:
- Municipal sewer cleaning project in Canada
- Urban drainage system maintenance in Southeast Asia
- Wastewater pipeline cleaning project in the USA
👉 Customers reported:
- 70% reduction in manual labor
- Significant improvement in cleaning efficiency
- Enhanced safety compliance
FAQ – Sewer Cleaning Robot
Q1: What is the minimum pipe size for operation?
A: The robot can operate in pipelines with a diameter of 600mm or above.
Q2: Is it suitable for hazardous sewer environments?
A: Yes, it features an explosion-proof and waterproof design, ideal for municipal use.
Q3: Can it handle heavy sludge and debris?
A: Absolutely. It is designed for high-load sludge removal and blockage clearing.
Get a Reliable Sewer Cleaning Robot Today
Looking for a professional sewer cleaning robot for sale for your municipal projects?
YG Machinery provides high-performance, cost-effective solutions trusted by clients worldwide.
👉 Contact us now to get:
- Project-based recommendations
- Detailed technical specifications
- Competitive factory pricing
Upgrade your municipal sewer cleaning with a safer, smarter, and more efficient solution today.
